Garrett ACE series detector - ACE Detector Components; ACE Illustration and Parts List

ACE Parts
No tools are required to assemble the ACE 250 or 150
enhanced metal detectors. 4 AA batteries are included
with the detector.
Before assembling your ACE metal detector ensure you
have the complete set of parts, which include:
• Control Housing with S-shaped Ramrod Stem
• Upper Stem
• Lower Stem
• Two (2) Knobs
• Two (2) Washers
• One (1) Threaded Bolt
• Searchcoil with Cable
If any part is missing, please contact your local dealer.
Garrett Metal Detectors
Ace 150 • Ace 250
Control
Housing
S-shaped
Ramrod Stem
Upper
Stem
Lower
Stem
Search
coil
Threaded
Bolt
Handle
Grip
Padded
Arm Cuff
LCD
Screen
Detector
Stand
Pushbutton
Controls
Washer
Knob
ACE Illustration
6
Spring
Clip
7
