Garrett ACE series detector - Connecting Cable to Housing; Installing Batteries; Adjusting Arm Cuff Position

7. The location of the arm cuff may be adjusted
by removing the screw in the bottom of the arm
rest and rotating the cuff 180°.
11
5. Insert the cable connector into the connector on
the housing and hand-tighten securely.
6. All ACE detectors come with batteries installed.
Slide cover back to replace batteries.
10
Garrett Metal Detectors
Ace 150 • Ace 250
