11.7.7 Secure the unit to the floor using 1/4” (6mm) mounting screws (not supplied). The mounting holes
in the plates may be used as a drill guide.
11.8 ELECTRICAL WIRING REQUIREMENTS
Comes with a standard American ground power cord. If the plug must be replaced or removed to
hardwire an AC junction box, use the following wiring list:
Green To Ground
Black To Line Hot
White To Line Neutral
Comes with a European power cord. If the plug must be replaced or removed to hardwire to an AC
junction box, use the following wiring list:
Green/Yellow To Ground
Brown To Line Hot
Blue To Line Neutral
