Gateway E-3200 - Default Chapter; Table of Contents

Contents i
Contents
Preface ..................................................................................... iii
Conventions Used in This Guide........................................................... iv
Safety Instructions................................................................................... v
Case Access ............................................................................ 1
Static Electricity Precautions .................................................................. 2
Opening the Case..................................................................................... 3
Closing the Case...................................................................................... 5
System Components ............................................................... 7
System board ........................................................................................... 8
Riser card ............................................................................................... 10
Back of riser card............................................................................ 10
Front of riser card ........................................................................... 10
I/O connectors........................................................................................ 12
Removing the System Board ................................................................ 13
Replacing the Processor........................................................................ 16
Setting the Jumpers................................................................................ 20
Configure mode.............................................................................. 20
Recovery mode............................................................................... 21
Installing Memory and Hardware......................................................... 23
ECC Memory ................................................................................. 23
Installing DIMMs.................................................................................. 24
Replacing and adding drives................................................................. 27
Drive Cabling Information............................................................. 28
Replacing the 3.5-inch diskette or CD-ROM drive ...................... 29
Installing an additional 3.5-inch device......................................... 30
Replacing the hard drive ................................................................ 32
Adding a second hard drive ........................................................... 33
Adding an expansion card..................................................................... 35
Heceta II hardware management.......................................................... 37
Installing LANDesk Client Manager ................................................... 38
Replacing the battery............................................................................. 39
Troubleshooting the battery installation........................................ 40
Using Your System Restoration CD..................................................... 42
