36
www.gateway.com
Replacing the hinge covers
Tools you need to complete this task:
Screws removed during this task:
To replace the hinge cover:
1 Follow the instructions under “Preventing static electricity discharge” on page 5.
2 Disconnect the AC adapter and modem and network cables, then prepare the
notebook by following the instructions in “Preparing the notebook” on page 6.
3 Turn the notebook over so the bottom is facing up.
4 Remove the battery by following the instructions in “Removing the battery” on
page 7.
5 Turn the notebook over so the top is facing up.
6 Remove the keyboard cover by following the instructions in “Replacing the keyboard
cover” on page 16.
7 Open the keyboard compartment by following the instructions in “Replacing the
keyboard” on page 18.
Important You do not need to disconnect the keyboard from the system board.
Flat-blade driver Scribe or non-marring tool
- OR -
Phillips #0 screwdriver
4 chrome 2.5 × 2.5 mm
(hinge cover)
5 chrome 2.5 × 2.5 mm
(keyboard)
