18
www.gateway.com
Replacing the keyboard
Tools you need to complete this task:
Screws removed during this task:
To replace the keyboard:
1 Follow the instructions under “Preventing static electricity discharge” on page 5.
2 Disconnect the AC adapter and modem and network cables, then prepare the
notebook by following the instructions in “Preparing the notebook” on page 6.
3 Turn the notebook over so the bottom is facing up.
4 Remove the battery by following the instructions in “Removing the battery” on
page 7.
5 Turn the notebook over so the top is facing up.
6 Open the LCD panel to the fully open position.
7 Remove the keyboard cover by following the instructions in “Replacing the keyboard
cover” on page 16.
Caution Be careful not to use too much force when opening the LCD panel.
Phillips #0 screwdriver
Flat-blade driver
5 chrome 2.5 × 2.5 mm
(keyboard)
