- 45 - LaserPro X252 & X380RX User Manual
SmartGUARD Page
After hardware installation, please enter the function menu on the control panel to enable the
SmartGUARD fire alarm.
SmartGUARD Enable / Disable:
Press directional key (left or right) to enable the SmartGUARD device or disable it.
Sensitivity
：
Press directional key (left or right) to set the sensitivity of SmartGUARD. There are five
sensitivity settings (1, 3, 5, 7, 9 seconds) that can be selected. Sensitivity is defined by the
delay time from when a fire is detected until the fire alarm alerts user, and automatically
shuts down the system. For example, if the sensor delay switch is set to the 3 second
position, the SmartGUARD will start an alarm and automatically shutdown the laser system
after detecting a fire for 3
seconds.
SmartGUARD Setting
Page
Relevant Buttons
Function
F1 (Back)
Back to previous page
F4 (Save)
Save your current settings



/


 Directional
Cycle SmartGUARD between Disable/ Enable



/



Directional
Scroll through the menu selections
Start / Stop Back to Main Work Page
Auto Focus Initiate the auto focus function
▲ / ▼
Manual Focus
Manually adjust the height of the work table (Z-axis)
Main Work Page
Press
F4
☼
Navigating to this page:
Functions Page
Select <
Machine Setting
>
from the menu
Machine Setting Page
Select <
SmartGUARD
>
from the menu
Set File Save Mode
Page
