Mains Supply 3 x 200- 240 VAC
AF-650 GP 20 HP 25 HP 30 HP 40 HP 50 HP
High/ Normal Load*
HD LD HD LD HD LD HD LD HD LD
Typical Shaft Output [kW] 15 18.5 18.5 22 22 30 30 37 37 45
Typical Shaft Output [HP]
at 208 V
20 25 25 30 30 40 40 50 50 60
Unit Size IP20 24 33 33 34 34
Unit Size IP55, 66 31 31 31 32 32
Output current
Continuous
(3 x 200-240 V) [A]
59.4 74.8 74.8 88 88 115 115 143 143 170
Intermittent
(60 sec overload)
(3 x 200-240 V) [A]
89.1 82.3 112 96.8 132 127 173 157 215 187
Continuous
KVA (208 V AC) [KVA]
21.4 26.9 26.9 31.7 31.7 41.4 41.4 51.5 51.5 61.2
Max. input current
Continuous
(3 x 200-240 V ) [A]
54 68 68 80 80 104 104 130 130 154
Intermittent
(60 sec overload)
(3 x 200-240 V ) [A]
81 74.8 102 88 120 114 156 143 195 169
Max. cable size, IP20
[mm
2
(AWG)]
2)
35 (2) 90 (3/0) 90 (3/0) 120 (4/0) 120 (4/0)
Max. cable size, IP
21/55/66 [mm
2
(AWG)]
2)
90 (3/0) 90 (3/0) 90 (3/0) 120 (4/0) 120 (4/0)
Max cable size with mains
disconnect
35 (2) 70 (3/0) 150 (MCM 300)
Max. mains fuses [A]
1
125 125 160 200 250
Estimated power loss
at rated max. load [W]
4)
624 737 740 845 874 1140 1143 1353 1400 1636
Weight,
Unit Size IP 55, 66 [kg]
45 45 45 65 65
Efficiency
4)
0.96 0.97 0.97 0.97 0.97
* Heavy duty (HD) = 160% torque during 60 s, Light duty (LD) = 110% torque during 60 s
