130BX140.12
elbac rotoMeniL CA
Motor
Stray capacitance
AC Line
Drive
Illustration 5.4: Alternate Signal Conductor Currents
High frequency currents can be coupled into the mains supplying the frequency converter when the mains conductors are located close to the motor cables.
High Power Service Manual for Unit Sizes 6x
68
5
