PositionType of spacer
Placed between groove 1 and 2Sample spacer
Placed between groove 1 and 2, and between 3 and 4.Digitization/OD spacers
(pair)
For digitization, the spacers should be placed with the digitization label facing up, and
the arrows pointing to the scan area. For OD measurements, the spacers should be
placed with the OD label facing up.
Membrane weight
The membrane weight is used to press fluorescent membranes flat against the fluor
stage. The use of a membrane weight improves image quality, since the membrane
weight removes air bubbles and reduces vibration of the membrane during scanning.
52 Amersham Typhoon Operating Instructions 29193226 AC
3 System description
3.3 Stages
3.3.2 Fluor stage with accessories
