110 • Appendix C - DeviceNet™ to Modbus™ Gateway
Color State Indication
Solid Unrecoverable Fault
Red
Flashing
Recoverable Fault
I/O Connection Timed Out
Solid Normal runtime operation
Green
Flashing
Device is idle or not
allocated to a master
Red / Green Alternating
Identify (Offline Connection
Set)
The LED on the left indicates the Module Status. The operation of the Module Status LED is described in Table 3.
Table 3 DeviceNet Module Status LED
Color State Indication
None Off No Power
Solid Unrecoverable Fault
Red
Flashing Recoverable Fault
Solid Normal operation
Green
Flashing Not Used
Red / Green Alternating Not used
