GE ASTAT XT QT 0008U Series User Manual

119 • Appendix C - DeviceNet™ to Modbus™ Gateway
C.11.3. Common Services
Implemented for
Service
Code
Class Level Instance Level
Service Name
0E
HEX
Yes Yes Get Attribute Single
10
HEX
No Yes Set Attribute Single
C.12. Start Settings Object (72
HEX –
1 Instance)
C.12.1. Class Attributes (Instance 0)
Attribute
ID
Name DeviceNet
Data Type
Data Value Access
Rule
1 Revision UINT 1 Get
C.12.2. Instance Attributes (Instance 1)
Attribute
ID
Name Range Default
Value
Access
Rule
Modbus
Address
1 Soft Start Curve 0-10 0 Get/Set 40025
2 Kickstart Time 0-10 (10
th
Sec) 0 Get/Set 40026
3 Starting
Voltage/Current
10-80 30 Get/Set 40027
4 Current Limit 100-500 400 Get/Set 40028
5 Ramp UP Time 1-90 10 Get/Set 40029
6 Max. Start Time 1-250 30 Get/Set 40030
7 Number of Starts 1-10 & 11 - OFF 10 Get/Set 40031
8 Duty Cycle Time 1-60 30 Get/Set 40032
9 Start_Lockout 1-60 15 Get/Set 40033
10 EOR Relay Delay 0-40 5 Get/Set 40034
C.12.3. Common Services
Implemented for
Service
Code
Class Level Instance Level
Service Name
0E
HEX
Yes Yes Get Attribute Single
10
HEX
No Yes Set Attribute Single
C.13. Stop Settings Object (73
HEX –
1 Instance)
C.13.1. Class Attributes (Instance 0)
Attribute
ID
Name DeviceNet
Data Type
Data Value Access
Rule
1 Revision UINT 1 Get
C.13.2. Instance Attributes (Instance 1)
Attribute
ID
Name Range Default
Value
Access
Rule
Modbus
Address
1 Soft Stop Curve 0-10 0 Get/Set 40041
2 Ramp DOWN Time 1-30 10 Get/Set 40042
3 End Torque 0-10 0 Get/Set 40043
C.13.3. Common Services
Implemented for
Service
Code
Class Level Instance Level
Service Name
0E
HEX
Yes Yes Get Attribute Single
10
HEX
No Yes Set Attribute Single
C.14. Dual Settings Object (74
HEX –
1 Instance)
C.14.1. Class Attributes (Instance 0)
Attribute Name DeviceNet Data Value Access
