GE ASTAT XT QT 0008U Series User Manual

118 • Appendix C - DeviceNet™ to Modbus™ Gateway
Attribute
ID
Name Description Access
Rule
Modbus
Address
09: Shorted SCR.
10: Long Start Time
11: Slow Speed Time
12: Reserved
13: External Fault
14: Wrong Parameters
15: EMI/RFI Fault
16: Too Many Starts
17: Reserved.
18: Thermistor.
19: Frequency.
25 Motor Fault
Current
Current at trip time (Amp) Get 40281
26-45 Actual_Data_Grou
p
20 actual parameters selected
by Setting Parameters 90-109
Get 40365-
40384
C.10.3. Common Services
Implemented for
Service
Code
Class Level Instance Level
Service Name
0E
HEX
Yes Yes Get Attribute Single
C.11. Main Parameter Object (71
HEX –
1 Instance)
C.11.1. Class Attributes (Instance 0)
Attribute
ID
Name DeviceNet
Data Type
Data Value Access
Rule
1 Revision UINT 1 Get
C.11.2. Instance Attributes (Instance 1)
Attribute
ID
Name Range Default
Value
Access
Rule
Modbus
Address
1 Starter Current 8-1400
(Amps)
58 Get/Set 40001
2 Motor Current 4-1750
(Amps)
58 Get/Set 40002
3 Line/Delta
Configuration
0 – Line
1 – Inside
Delta
0 Get/Set 40003
4 Undercurrent FLT 0-90 (% of
Im)
0 Get/Set 40004
5 Undercurrent DLY 1-40 (Sec) 10 Get/Set 40005
6 O/C JAM Fault 200-850
(% of Im)
400 Get/Set 40006
7 O/C JAM Delay 0-50
(0.5 Sec.)
5 Get/Set 40007
8 Overload Class 75-150
(% of Im)
115 Get/Set 40008
9 Overload Protect 1-10 (Sec.) 4 Get/Set 40009
10 Under voltage FLT 120-600
(Volt)
300 Get/Set 40010
11 Under voltage DLY 1-10 (Sec) 5 Get/Set 40011
12 Over voltage FLT 250-750
(Volt)
400 Get/Set 40012
13 Over voltage DLY 1-10 (Sec) 2 Get/Set 40013
