GE Corometrics 172 - RS-232 C Connectors; Telemetry Connector

Revision D 170 Series Monitor 3-15
2003023-001
Controls, Indicators, and Connectors: Rear Panel Connectors
RS-232C Connectors
Two RS-232C connectors are provided for interfacing to peripheral equipment such
as:
 a maternal non-invasive blood pressure monitor
 a Nellcor Model N-400 Fetal Oxygen Saturation Monitor
 a central information system that uses Hewlett-Packard’s Digital Series
Interface Protocol
Contact your Service Representative for more information.
CAUTION
NON-DESTRUCTIVE VOLTAGE—The maximum non-
destructive voltage that may be applied to the rear panel
connectors is 0 V. Do not attempt to connect cables to these
connectors without contacting your Biomedical Engineering
Department or Service Representative. This is to ensure the
connectors comply with leakage-current requirements of one of
the following applicable standards: Underwriters Laboratories
UL-2601.1, Canadian Standards Associations CSA 22.2 No. 125,
or International Electrotechnical Commission EN60601.1.
Telemetry Connector
This high-density 15-pin connector is intended for future interfacing to the receiver
of a Corometrics telemetry system. Contact your Service Representative for more
information.
IMPORTANT
TELEMETRY—For proper operation when using a telemetry
system, disconnect all transducers from the front panel of the 170
Series Monitor. Refer to the operator’s manual for your telemetry
system for more information.
