GE MEDICAL SYSTEMS CT 9800 QUICK SYSTEM
Rev. 1 Direction 18000
6-A-1
APPENDIX A BMC / ERCC & HIB Switch & Jumper Settings
NOTE: Before beginning this installation or if the HIB or BMC/ERCC boards are replaced, the following dip
switch settings must be checked and verified.
STCT AP INTERFACE BOARD (HIB)
SWITCH
LOCATION
POSITIONS ON POSITIONS OFF
C9 1,4,5 2,3,6,7,8
D1 4,6,8 1,2,3,5,7
F12 1,3 2,4,5,6,7,8
K2 1 2,3,4,5,6,7,8
ARGUS DISK CONSTROLLER (INTEL DISK CONT) if present
Note: Refer to Illustration 6-A-1 for a chart of the jumper locations.
BMC PRIORITY JUMPERS: P17, P18, P19, P20 INSTALLED
P10, P11, P12, P13, P14, P15, P16 REMOVED
DEVICE CODE JUMPERS: P2, P4, INSTALLED
P1, P3, P5, P6 REMOVED
MICRO BUS JUMPERS: P8, P9 INSTALLED
PCLK TEST JUMPER: P7 INSTALLED
S/140 ERCC/BMC BOARD (ON ZEBRA SYSTEMS THIS BOARD IS PART OF THE FCO UPGRADE)
Note: Refer to Illustration 6-A-2 for a chart of the jumper locations.
OVERDRIVE SWITCH SETTING: POSITIONS 1, 5, 6, ON
SW1 POSITIONS 2, 3, 4, 7 OFF
ERCC ENABLE JUMPERS: W1, W3 INSTALLED
W2 REMOVED
DUMPER RESISTOR JUMPERS: R27, R30, R43 INSTALLED
R31, R33 REMOVED
