GE MEDICAL SYSTEMS CT 9800 QUICK SYSTEM
Rev. 1 Direction 18000
8-1-6
TABLE 8-1
DIA STATUS BITS DECODE
BIT NAME WHAT TO DO
0 Control Full The adapter is talking to another disk drive and the rest of the status word
should be ignored.
For single disk drive systems or when running diagnostics on single or dual
disk drive systems this bit should always be a 0.
If this bit is a 1, the problem may be the 960 (DISK CONTROLLER Board), 951
(ADAPTER 1 Board) or cabling between the CPU backplane and the Adapter
chassis.
For dual disk drive systems this bit may be set occasionally and should not
be considered an error. If this bit fails to clear, then troubleshoot as
described above.
1 R/W Done This bit is normally a 1. A 04xxx, 05xxx, or 06xxx usually indicates the
status word is a DIA Status. If the bit never sets, there is a problem
communicating with the requested disk drive. Possible problems are:
DISK CONTROLLER Board has incorrect device code, is missing, defective,
or is in the wrong slot.
Cabling from CPU Backplane to Adapter chassis is defective or on wrong
slot
Adapter is turned OFF, Adapter 1 board is defective
Cable from Adapter to Disk Drive is on the wrong slot or is defective
Disk Drive is not ready of DRIVE LOGIC Board is defective
2 Drive 0 is done
executing a
command
This bit is normally a 0. It may occasionally be set if other errors occur. This bit
gives no useful troubleshooting information.
3 Drive 1 is done
executing a
command
This bit is normally a 0. It may occasionally be set if other errors occur. If this
system has only a single disk drive, this bit should never be set. If it is set,
possible problems are:
DISK CONTROLLER Board
Cabling from the Adapter to the CPU Backplane
ADAPTER 1 Board
4 Drive 2 is done
executing a
command
This bit should never be set. If it is set possible problems are:
DISK CONTROLLER Board
Cabling from the Adapter to the CPU Backplane
ADAPTER 1 Board
5 Drive 3 is done
executing a
command
Same as Bit 4.
6 Parity Error An error was detected while transferring dat or status between the DATA
CHANNEL CONTROL Board and the ADAPTER 2 Board. Most likely causes:
ADAPTER 2 Board
DISK CONTROLLER Board
DATA CHANNEL INTERFACE Board
Cabling between the Adapter and CPU Backplane
