D20 Chassis
The D20 chassis is available in two versions:
• Standard single slot with one horizontal Eurocard slot for mounting the
D20ME/ME II board for the non-VME compatible version.
• Full VME equipped with five horizontal expansion slots for VME compatible
printed circuit boards.
Table
The D20 has a 3U horizontal slot chassis for 19” rack mounting. There are two types
of chassis:
Chassis Type Part # Description
D20 non-VME
(1 slot horizontal)
500-0305 Single Slot MX Chassis with backplane, external
power connections, and 7 serial I/O ports
D20 VME
(5 slot horizontal)
500-0280 MX Chassis with 5 card VME backplane
Chassis
Compatibility
See “Appendix A: Product Combinations”, for the possible matching of main
processor board, Ethernet and m
emory expansion card combinations with Chassis
types.
D20 Kit
Components
D20 Main Chassis kit contains:
• Chassis
• Main processor board
• Power supply
• WESMAINT maintenance port cable
• Software loaded into the main processor, See “D20ME/ME II Factory Fitted
Software” on page 25.
• Term
ination panel: included on the 500-0305 single-slot, not included on the
500-0280 MX with VME backplane.
Modems are options for the Main Chassis kit.
