GE D25 User Manual

D25
User's Manual
GE Grid Solutions
18
994-0081-3.00-21 GE Information
Chapter 2: Installing the D25
Installation Tools List
Installation
Tools List
Before you begin the install of the D25, gather the following:
• A Flat Screwdriver with 0.6x3.5 mm blade (for terminal block wiring)
• A #2 Phillips Screwdriver (for rack mounting the unit)
• Wire Cutters
• Wire Strippers
• Wire Crimping Tool
• Tie-wraps (for gathering extra wire)
•
Multi-meter (for testing points)
Installation Steps
Procedure
Follow these steps to install the D25:
Step
Action
1
Unpack the D25.
2
Using the First Look at the D25 section of this guide, inspect the D25
for damage.
Note: Report any damage immediately to GE Grid Solutions. See:
Product Safety for contact details.
3
Loosen the D25 front panel and remove the battery “PULL” tabs (one
for the Mainboard battery, and one for the optional Memory
Expansion card battery). The D25 is delivered with these tabs in
place to insulate the battery during shipment.
4
Install the D25. Follow the procedure set out in section: Connecting
Field Wiring.
5
Carry out all field wiring connections and jumper settings
configuration as set out in section: Configuring the D25 to work with
a DNP3 I/O Module:
• Power
• Serial and Ethernet communication
•
Input and output pinouts
6
Power-up the D25 and check for normal operation. See section:
Configuring the D25 to work with a DNP3 I/O Module. Some testing
requires that code and configuration files have been downloaded to
the D25.
If the front panel Power and Run LEDs do not show normal
operation, then use WESMAINT to inspect the error messages from
the self-diagnostics and ascertain what is malfunctioning.
