Graphic Display Panel (GDP) and Color GDP (CGDP) Overview
GDP/CGDP
Diagrams
A Graphic Display Panel (GDP) or a Color Graphic Display Panel (CGDP)
option has been made available for applications where graphic front-panel
display and control of system inputs and outputs is desired.
This diagram shows a D25 front panel with the GDP option installed.
M ultifunction I ED
D25
COM M U N I CATI ON SW ES M A I N T
Tr a ns m i t Recei ve
XCOM 2
XCOM 1
I ED 2
I ED 1
Pow er
Ru n
OPERA TI ON
Dis ab l e
Enable
CON T ROLS
GE Energy Services
F
+
++
+
This diagram shows a D25 front panel with the CGDP option installed.
Detailed
Description
The touch-sensitive GDP/CGDP can display a selection of customized
graphic displays, each representing a set of analog and digital input and
output points.
Using the touch-sensitive screen, an operator can select various displays,
select points to monitor and issue control commands
