The breaker control element contains the auxiliary logic for status and serves as the interface for opening and closing of a
circuit breaker from protection, autoreclose, SCADA, or through the front panel interface. The breaker control element can
be used to create interlocking functionality. For greater security in determination of the breaker position, both the 52/a and
52/b auxiliary contacts are used with reporting of the discrepancy between them.
To use this element, configure the contact outputs that trip and close the breaker to use FlexLogic operands BREAKER 1 OFF
CMD (or BREAKER 1 TRIP A/B/C in the case of single-pole tripping) and BREAKER 1 ON CMD, and configure the breaker control
element inputs as described here.

BREAKER 1 AR BLOCK:
Disabled
Range: Disabled, Enabled

BREAKER 1 NAME:
Bkr 1
Range: up to six alphanumeric characters

BREAKER 1 MODE:
3-Pole
Range: 3-Pole, 1-Pole

BREAKER 1 OPEN:
Off
Range: FlexLogic operand

BREAKER 1 BLK OPEN:
Off
Range: FlexLogic operand

BREAKER 1 CLOSE:
Off
Range: FlexLogic operand

BREAKER 1 BLK CLOSE:
Off
Range: FlexLogic operand

BREAKER1 ΦA/3P CLSD:
Off
Range: FlexLogic operand

BREAKER1 ΦA/3P OPND:
Off
Range: FlexLogic operand

BREAKER 1 ΦB CLOSED:
Off
Range: FlexLogic operand

BREAKER 1 ΦB OPENED:
Off
Range: FlexLogic operand

BREAKER 1 ΦC CLOSED:
Off
Range: FlexLogic operand

BREAKER 1 ΦC OPENED:
Off
Range: FlexLogic operand

BREAKER 1 TOPERATE:
70 ms
Range: 0 to 65535 s in steps of 1

BREAKER 1 EXT ALARM:
Off
Range: FlexLogic operand

BREAKER 1 ALARM
DELAY: 0.000 s
Range: 0.000 to 65.535 s in steps of 0.001

MANUAL CLOSE RECAL1
TIME: 0.000 s
Range: 0.000 to 65.535 s in steps of 0.001

BREAKER 1 OPEN
SEAL-IN: 0.000 s
Range: 0.000 to 65.535 s in steps of 0.001

BREAKER 1 OUT OF SV:
Off
Range: FlexLogic operand

BREAKER 1 RACKED-IN:
Off
Range: FlexLogic operand

BREAKER 1 EVENTS:
Disabled
Range: Disabled, Enabled
