CHAPTER 5: SETTINGS GROUPED ELEMENTS
D30 LINE DISTANCE PROTECTION SYSTEM – INSTRUCTION MANUAL 5-189
5
Each of the six setting group menus is identical. Setting group 1 (the default active group) is active automatically when no
other group is active.
If the device incorrectly switches to group 1 after power cycling, upgrade the firmware to version 7.31 or later to correct
this issue.
5.7.3 Line pickup
SETTINGS  GROUPED ELEMENTS  SETTING GROUP 1(6)  LINE PICKUP

 POWER SWING
 DETECT
See page 5-209

 LOAD ENCROACHMENT

See page 5-218

 PHASE CURRENT

See page 5-219

 NEUTRAL CURRENT

See page 5-231

 WATTMETRIC
 GROUND FAULT
See page 5-239

 GROUND CURRENT

See page 5-243

 NEGATIVE SEQUENCE
 CURRENT
See page 5-246

 VOLTAGE ELEMENTS

See page 5-252
 LINE PICKUP


LINE PICKUP
FUNCTION: Disabled
Range: Disabled, Enabled

LINE PICKUP SIGNAL
SOURCE: SRC 1
Range: SRC 1, SRC 2

PHASE IOC LINE
PICKUP: 1.000 pu
Range: 0.020 to 30.000 pu in steps of 0.001

LINE PICKUP UV PKP:
0.700 pu
Range: 0.004 to 3.000 pu in steps of 0.001

LINE END OPEN PICKUP
DELAY: 0.150 s
Range: 0.000 to 65.535 s in steps of 0.001

LINE END OPEN RESET
DELAY: 0.090 s
Range: 0.000 to 65.535 s in steps of 0.001

LINE PICKUP OV PKP
DELAY: 0.040 s
Range: 0.000 to 65.535 s in steps of 0.001

AR CO-ORD BYPASS:
Enabled
Range: Disabled, Enabled

AR CO-ORD PICKUP
DELAY: 0.045 s
Range: 0.000 to 65.535 s in steps of 0.001

AR CO-ORD RESET
DELAY: 0.005 s
Range: 0.000 to 65.535 s in steps of 0.001

TERMINAL OPEN:
Off
Range: FlexLogic operand

AR ACCELERATE:
Off
Range: FlexLogic operand
