GE D30 - Page 61

CHAPTER 3: INSTALLATION PANEL CUTOUTS
D30 LINE DISTANCE PROTECTION SYSTEM – INSTRUCTION MANUAL 3-9
3
For side-mounting D30 devices with the standard front panel, use the following figures.
Figure 3-9: Vertical side-mounting installation (standard front panel)
