3-22 D30 LINE DISTANCE PROTECTION SYSTEM – INSTRUCTION MANUAL

WIRING CHAPTER 3: INSTALLATION

~67 module ~4A module ~4B module ~4C module

Terminal

assignment

Output Terminal

assignment

Output Terminal

assignment

Output Terminal

assignment

Output

~1Form-A~1 Not Used ~1 Not Used ~1 Not Used

~2Form-A~2Solid-State~2 Solid-State ~2 Solid-State

~3Form-A~3 Not Used ~3 Not Used ~3 Not Used

~4Form-A~4Solid-State~4 Solid-State ~4 Solid-State

~5Form-A~5 Not Used ~5 Not Used ~5 Not Used

~6Form-A~6Solid-State~6 Solid-State ~6 Solid-State

~7Form-A~7 Not Used ~7 Not Used ~7 Not Used

~8Form-A~8Solid-State~8 Solid-State ~8 Solid-State

~4D module ~4L module

Terminal

assignment

Output Terminal

assignment

Output

~1a, ~1c 2 Inputs ~1 2 Outputs

~2a, ~2c 2 Inputs ~2 2 Outputs

~3a, ~3c 2 Inputs ~3 2 Outputs

~4a, ~4c 2 Inputs ~4 2 Outputs

~5a, ~5c 2 Inputs ~5 2 Outputs

~6a, ~6c 2 Inputs ~6 2 Outputs

~7a, ~7c 2 Inputs ~72 Outputs

~8a, ~8c 2 Inputs ~8 Not Used
