CHAPTER 3: INSTALLATION WIRING
D30 LINE DISTANCE PROTECTION SYSTEM – INSTRUCTION MANUAL 3-21
3
~3 Form-C ~3Form-C~3Form-C~3Form-A
~4 Form-C ~4Form-C~4Form-C~4Form-A
~5 Fast Form-C ~5a, ~5c 2 Inputs ~5Form-C~5a, ~5c 2 Inputs
~6 Fast Form-C ~6a, ~6c 2 Inputs ~6Form-C~6a, ~6c 2 Inputs
~7 Fast Form-C ~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs
~8 Fast Form-C ~8a, ~8c 2 Inputs ~8a, ~8c 2 Inputs ~8a, ~8c 2 Inputs
~6P module ~6R module ~6S module ~6T module
Terminal
assignment
Output or
input
Terminal
assignment
Output or
input
Terminal
assignment
Output or
input
Terminal
assignment
Output or
input
~1 Form-A ~1Form-A~1Form-A~1Form-A
~2 Form-A ~2Form-A~2Form-A~2Form-A
~3 Form-A ~3Form-C~3Form-C~3Form-A
~4 Form-A
~4Form-C~4Form-C~4Form-A
~5 Form-A ~5a, ~5c 2 Inputs ~5Form-C~5a, ~5c 2 Inputs
~6 Form-A ~6a, ~6c 2 Inputs ~6Form-C~6a, ~6c 2 Inputs
~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs
~8a, ~8c 2 Inputs ~8a, ~8c 2 Inputs ~8a, ~8c 2 Inputs ~8a, ~8c 2 Inputs
~6U module ~6V module ~6W module 6X module
Terminal
assignment
Output or
input
Terminal
assignment
Output or
input
Terminal
assignment
Output or
input
Terminal
assignment
Output or
input
~1 Form-A ~1 Form-A ~1a - ~2a Output ~1a, ~1b 2 Inputs
~2 Form-A ~2 Form-A ~3a - ~4a Output ~2a, ~2b 2 Inputs
~3 Form-A ~3 Form-C ~5a - ~6a Output ~3a, ~3b 2 Inputs
~4 Form-A ~4 2 Outputs ~7a - ~8a Output ~4a, ~4b 2 Inputs
~5 Form-A ~5a, ~5c 2 Inputs ~9a - ~10a Output ~5a, ~5b 2 Inputs
~6 Form-A ~6a, ~6c 2 Inputs ~11a - ~12a Output ~7a, ~7b 2 Inputs
~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs ~13a - ~14a Output ~8a, ~8b 2 Inputs
~8a, ~8c 2 Inputs ~8a,
~8c 2 Inputs ~15a - ~16a Output ~9a, ~9b 2 Inputs
--- --- --- --- ~17a - ~18a Output ~10a, ~10b 2 Inputs
--- --- --- --- ~1b - ~2b Output ~11a, ~11b 2 Inputs
--- --- --- --- ~3b - ~4b Output ~13a, ~13b 2 Inputs
--- --- --- --- ~5b - ~6b Output ~14a, ~14b 2 Inputs
--- --- --- --- ~7b - ~8b Output ~15a, ~15b 2 Inputs
--- --- --- --- ~9b - ~10b Output ~16a, ~16b 2 Inputs
--- --- --- --- ~11b - ~12b Output ~17a, ~17b 2 Inputs
--- --- --- --- ~13b - ~14b Output --- ---
--- --- --- --- ~15b - ~16b Output --- ---
--- --- --- --- ~17b - ~18b Output --- ---
~6K module ~6L module ~6M module ~6N module
Terminal
assignment
Output Terminal
assignment
Output or
input
Terminal
assignment
Output or
input
Terminal
assignment
Output or
input
