Chapter 2. Initial Setup
22 DigitalFlow™ Multipurpose Ultrasonic Liquid Flowmeter Startup Guide (1- and 2-Channel)
2.5.3 1- and 2-Channel Meters (cont.)
4. Press [F1]-[F4] to select the Total Decimal Digits (the digits to the right of the decimal point) in the totalized flow
display.
2.5.3a Mass Flow
If the Mass Flow prompt in the SETUP submenu is not enabled, skip this sub-section. However, the following
programming sequence appears if Mass Flow is enabled.
1. Use the [F1]-[F4] keys to select the desired Mass Flow units, listed in Table 5.
2. Use the
[F1]-[F4] keys to select the desired Mass Flow Time units.
3. Use the [F1]-[F4] keys to select the MDOT Decimal Digits (the digits to the right of the decimal point) for displaying
mass flow.
4. Use the [F1]-[F4] keys to select the Mass (Totalizer) units, listed in Table 5.
5. Use the [F1]-[F4] keys to select the Mass Decimal Digits (the digits to the right of the decimal point) for displaying
totalized mass flow.
Table 4: Totalizer Unit Options
English Totalizer Units Metric Totalizer Units
Gal - U.S. Gallons L - Liters
MGAL - Mega U.S. gallons ML - Megaliters
ft
3
- Cubic Feet m
3
- Cubic Meters
Mft
3
- Mega Cubic Feet Mm
3
- Mega Cubic Meters
BBL - Barrels BBL - Barrels
MBBL - Megabarrels MBBL - Megabarrels
Acre-inches
Acre-feet
Table 5: Available Mass Flow Units
English Metric
LB = Pounds KG = Kilograms
KLB = Thousands of LB TONNE = Metric Tons (1000 KG)
MMLB = Millions of LB
TONS = Tons (2000 LB)
