Chapter 1. Installation
4 DigitalFlow™ GF868 Startup Guide (1 and 2-Channel)
1.4 Installing a Flowcell (cont.)
Figure 1: Model GF868 Flowmeter System
Transducer
Flowcell
Temperature Transmitter
Pressure Transmitter
Preamp
Transducer
Electronics Console
GAS
FLOW
