Appendix C. Optional Enclosures
DigitalFlow™ GF868 Startup Guide (1 and 2-Channel) 55
GF868
19.00 (483)
18.25 (464)
2.25 5.22
11.37
11.82
13.13
4.19 (106)
15.70 (399)
3.31 (84)
14.83 (377)
16.99 (432)
A / OUTALARMS A / IN RTD IN
(289)
(300)
(333)
(57) (133)
Figure 14: Model GF868 Rack Mount Enclosure (ref. dwg #712-1078)
