Appendix D. Measuring P and L Dimensions
60 DigitalFlow™ GF868 Startup Guide (1 and 2-Channel)
Figure 17: Top View of Transducer Installations
Pipe O.D.
L
P
T
Pipe Thickness
L
T
P
CL
180° Installation
Bias 90° Installation
