Chapter 1. Programming Site Data
22 DigitalFlow™ GF868 Programming Manual (1-Channel)
1.10 Entering Setup Data
The signal limits and response times for the Model GF868 are specified using the SETUP submenu. While following the
programming instructions, refer to Figure 13 on page 89. The following four submenus are included in this section:
• SIGNL - set the parameters related to the transducer signal
• AVRG - specify the response of the meter to step changes
• INIT - initialize some parameters to default values.
• ADVAN - enter mass flow and K-factor data.
Enter the
SETUP submenu by pressing [ and [F1] at the initial User Program screen and complete the following steps:
Proceed to the appropriate section to program the option selection made at the above prompt. Remember to record all
programmed data in Appendix B, Data Records.
SETUP
Press [F1]-[F4] to select the desired SETUP option.
PROGRAM
SET UP
SET UP
last selection appears here
SIGNL AVRG INIT ADVAN
To Next Page
