Chapter 2. Displaying Data
38 DigitalFlow™ GF868 Programming Manual (1-Channel)
2.2 The BIG Submenu
The BIG format, which is the Model GF868’s default power up format, displays one measurement in large print. To
select the BIG format and the measurement to display in this format, follow the instructions in this section.
Upon power up, a standard measurement mode display (similar to the one shown below) appears. Press the appropriate
side of the
[SCREEN] key to activate the desired pane of the display screen, and complete the following steps:
Note: See Chapter 3, Operation, of the Startup Guide for more details on selecting a measurement parameter to
display.
site label site file 
The default power up screen is already in BIG mode. If a different display mode is
active, access the Display Menu by pressing the [DISP] key.
Velocity Ft/s
6.95
(error codes appear here)
VEL VOLUM +TOTL -TOTL
DISPLAY FEATURES 
Press [F1] to select the BIG option. The measurement mode screen reappears with
the display in the BIG format.
DISPLAY FORMAT
previous selection appears here
BIG DUAL GRAPH LOG
site label site file 
Use the [F1]-[F4], [ and [ keys to select the desired display parameter option.
See Table 5 for a complete description of the available options.
Velocity Ft/s
6.95
(error codes appear here)
VEL VOLUM +TOTL -TOTL
Table 5: Measurement Parameter Options
Option Bar Choice Description
[F1] = VEL Flow Velocity
[F2] = VOLUM Volumetric Flow
[F3] = +TOTL Forward Totalized Volume Flow
[F4] = -TOTL Reverse Totalized Volume Flow
[
+ [F1] = TIME Total Flow Measurement Time
[
+ [F2] = MDOT Mass Flow
[
+ [F3] = +MASS Forward Totalized Mass Flow
[
+ [F4] = -MASS Reverse Totalized Mass Flow
[
+ [ + [F1] = DIAG Diagnostic
