5.2 PRODUCT SETUP 5 SETTINGS
5
The table shows which of DNP 3.0, IEC 60870-5-104, IEC 60870-5-103, and IEC 61850 protocols are operational on the
RS232, RS485, and Ethernet ports. It shows all possible combinations of the PROTOCOL and DNP CHANNEL 1(2) PORT set-
tings.
j) DNP PROTOCOL
PATH: SETTINGS PRODUCT SETUP COMMUNICATIONS DNP PROTOCOL
Table 5–6: PORT AND PROTOCOL COMBINATIONS
PROTOCOL
SETTING
DNP CHANNEL 1(2) PORT
SETTINGS
RS232 RS485 ETHERNET
DNP Channel 1: Eth TCP
Channel 2: Eth TCP
Modbus Modbus DNP, Modbus, IEC 61850
Channel 1: Eth TCP
Channel 2: none
Modbus Modbus DNP, Modbus, IEC 61850
Channel 1: none
Channel 2: Eth TCP
Modbus Modbus DNP, Modbus, IEC 61850
Channel 1: Eth UDP
Channel 2: none
Modbus Modbus DNP, Modbus, IEC 61850
Channel 1: Eth TCP
Channel 2: RS485
Modbus DNP DNP, Modbus, IEC 61850
Channel 1: Eth TCP
Channel 2: RS232
DNP Modbus DNP, Modbus, IEC 61850
Channel 1: Eth UDP
Channel 2: RS485
Modbus DNP DNP, Modbus, IEC 61850
Channel 1: Eth UDP
Channel 2: RS232
DNP Modbus DNP, Modbus, IEC 61850
Channel 1: RS485
Channel 2: Eth TCP
Modbus DNP DNP, Modbus, IEC 61850
Channel 1: RS232
Channel 2: Eth TCP
DNP Modbus DNP, Modbus, IEC 61850
Channel 1: RS485
Channel 2: RS232
DNP DNP Modbus, IEC 61850
Channel 1: RS232
Channel 2: RS485
DNP DNP Modbus, IEC 61850
Channel 1: RS485
Channel 2: none
Modbus DNP Modbus, IEC 61850
IEC 104 Modbus Modbus IEC 104, Modbus, IEC 61850
IEC 103 Modbus IEC 103 Modbus, IEC 61850
DNP PROTOCOL
DNP CHANNELS
Range: see sub-menu below
MESSAGE
DNP ADDRESS:
1
Range: 0 to 65519 in steps of 1
MESSAGE
DNP NETWORK
CLIENT ADDRESSES
Range: see sub-menu below
MESSAGE
DNP TCP/UDP PORT
NUMBER: 20000
Range: 0 to 65535 in steps of 1
MESSAGE
DNP UNSOL RESPONSE
FUNCTION: Disabled
Range: Enabled, Disabled
MESSAGE
DNP UNSOL RESPONSE
TIMEOUT: 5 s
Range: 0 to 60 s in steps of 1
MESSAGE
DNP UNSOL RESPONSE
MAX RETRIES: 10
Range: 1 to 255 in steps of 1
MESSAGE
DNP UNSOL RESPONSE
DEST ADDRESS: 1
Range: 0 to 65519 in steps of 1
To Next Page
