6-16 G30 Generator Protection System GE Multilin
6.3 METERING 6 ACTUAL VALUES
6
6.3.2 TRANSFORMER
PATH: ACTUAL VALUES  METERING  TRANSFORMER  DIFFERENTIAL AND RESTRAINT
The metered differential current, restraint current, second harmonic current, and fifth harmonic current are displayed for
each phase. Refer to the Percent differential section in chapter 5 for details on how these values are calculated.
If differential current in any phase is below the hard-coded cutoff of 0.04 pu, then the differential, 2nd harmonic, and 5th
harmonic currents are forced to zero.
 DIFFERENTIAL AND
 RESTRAINT
REFERENCE WINDING:
Winding 1
MESSAGE
DIFF PHASOR Iad:
0.000 pu 0.0°
MESSAGE
REST PHASOR Iar:
0.000 pu 0.0°
MESSAGE
DIFF 2ND HARM Iad:
0.0% fo 0.0°
MESSAGE
DIFF 5TH HARM Iad:
0.0% fo 0.0°
MESSAGE
DIFF PHASOR Ibd:
0.000 pu 0.0°
MESSAGE
REST PHASOR Ibr:
0.000 pu 0.0°
MESSAGE
DIFF 2ND HARM Ibd:
0.0% fo 0.0°
MESSAGE
DIFF 5TH HARM Ibd:
0.0% fo 0.0°
MESSAGE
DIFF PHASOR Icd:
0.000 pu 0.0°
MESSAGE
REST PHASOR Icr:
0.000 pu 0.0°
MESSAGE
DIFF 2ND HARM Icd:
0.0% fo 0.0°
MESSAGE
DIFF 5TH HARM Icd:
0.0% fo 0.0°
