B-40 G30 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
6471 Overfrequency 1 Block 0 to 4294967295 --- 1 F300 0
6473 Overfrequency 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
6474 Overfrequency 1 Pickup 20 to 65 Hz 0.01 F001 6050
6475 Overfrequency 1 Pickup Delay 0 to 65.535 s 0.001 F001 500
6476 Overfrequency 1 Reset Delay 0 to 65.535 s 0.001 F001 500
6477 Overfrequency 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
6478 Overfrequency 1 Events 0 to 1 --- 1 F102 0 (Disabled)
6479 Reserved (4 items) 0 to 1 --- 1 F001 0
647D ...Repeated for Overfrequency 2
648A ...Repeated for Overfrequency 3
6497 ...Repeated for Overfrequency 4
Accidental Energization (Read/Write Grouped Setting)
6650 Accidental Energization Function 0 to 1 --- 1 F102 0 (Disabled)
6651 Accidental Energization Source 0 to 5 --- 1 F167 0 (SRC 1)
6652 Accidental Energization Arming Mode 0 to 1 --- 1 F193 0 (UV AND
OFFLINE)
6653 Accidental Energization OC Pickup 0 to 3 pu 0.001 F003 300
6655 Accidental Energization UV Pickup 0 to 3 pu 0.001 F003 500
6657 Accidental Energization Offline 0 to 4294967295 --- 1 F300 0
6659 Accidental Energization Block 0 to 4294967295 --- 1 F300 0
665B Accidental Energization Target 0 to 2 --- 1 F109 0 (Self-reset)
665C Accidental Energization Events 0 to 1 --- 1 F102 0 (Disabled)
665D Reserved (5 items) 0 to 65535 --- 1 F001 0
Loss of Excitation (Read/Write Grouped Setting)
666A Loss Of Excitation Function 0 to 1 --- 1 F102 0 (Disabled)
666B Loss Of Excitation Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
666C Loss Of Excitation Center 1 0.1 to 300 ohm 0.01 F001 1000
666D Loss Of Excitation Radius 1 0.1 to 300 ohm 0.01 F001 800
666E Loss Of Excitation UV Supervision Enable 1 0 to 1 --- 1 F102 1 (Enabled)
666F Loss Of Excitation Pickup Delay 1 0 to 65.535 s 0.001 F001 50
6670 Loss Of Excitation Center 2 0.1 to 300 ohm 0.01 F001 1200
6671 Loss Of Excitation Radius 2 0.1 to 300 ohm 0.01 F001 1000
6672 Loss Of Excitation UV Supervision Enable 2 0 to 1 --- 1 F102 1 (Enabled)
6673 Loss Of Excitation Pickup Delay 2 0 to 65.535 s 0.001 F001 500
6674 Loss Of Excitation UV Supervision 0 to 1.25 pu 0.001 F001 700
6675 Loss Of Excitation Block 0 to 4294967295 --- 1 F300 0
6677 Loss Of Excitation Target 0 to 2 --- 1 F109 0 (Self-reset)
6678 Loss Of Excitation Events 0 to 1 --- 1 F102 0 (Disabled)
6679 Reserved (5 items) 0 to 65535 --- 1 F001 0
Sensitive Directional Power (Read/Write Grouped Setting) (2 modules)
6680 Sensitive Directional Power 1 Function 0 to 1 --- 1 F102 0 (Disabled)
6681 Sensitive Directional Power 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
6682 Sensitive Directional Power 1 RCA 0 to 359 degrees 1 F001 0
6683 Sensitive Directional Power 1 Calibration 0 to 0.95 degrees 0.05 F001 0
6684 Sensitive Directional Power 1 STG1 SMIN -1.2 to 1.2 pu 0.001 F002 100
6685 Sensitive Directional Power 1 STG1 Delay 0 to 600 s 0.01 F001 50
6686 Sensitive Directional Power 1 STG2 SMIN -1.2 to 1.2 pu 0.001 F002 100
6687 Sensitive Directional Power 1 STG2 Delay 0 to 600 s 0.01 F001 2000
6688 Sensitive Directional Power 1 Block 0 to 4294967295 --- 1 F300 0
668A Sensitive Directional Power 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
668B Sensitive Directional Power 1 Events 0 to 1 --- 1 F102 0 (Disabled)
668C Reserved (5 items) 0 to 65535 --- 1 F001 0
6691 ...Repeated for Sensitive Directional Power 2
Table B–10: MODBUS MEMORY MAP (Sheet 32 of 64)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
