B-46 G30 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
Temp Monitor Actual Values (Read Only Non-Volatile)
81C0 Reserved Register T1 -55 to 125 C 1 F002 -55
81C1 Reserved Register T2 -55 to 125 C 1 F002 125
81C2 Reserved Register T3 -2147483647 to
2147483647
--- 1 F004 0
81C4 Reserved Register T4 0 to 4294967295 --- 1 F003 0
81C6 Reserved Register T5 0 to 4294967295 --- 1 F003 0
81C8 Reserved Register T6 0 to 4294967295 --- 1 F003 0
81CA Reserved Register T7 0 to 4294967295 --- 1 F003 0
81CC Reserved Register T8 0 to 4294967295 --- 1 F003 0
EGD Fast Production Status (Read Only Non-Volatile and Read Only)
83E0 EGD Fast Producer Exchange 1 Signature 0 to 65535 --- 1 F001 0
83E1 EGD Fast Producer Exchange 1 Configuration Time 0 to 4294967295 --- --- F003 0
83E3 EGD Fast Producer Exchange 1 Size 0 to 65535 --- 1 F001 0
EGD Slow Production Status (Read Only Non-Volatile and Read Only) (2 modules)
83F0 EGD Slow Producer Exchange 1 Signature 0 to 65535 --- 1 F001 0
83F1 EGD Slow Producer Exchange 1 Configuration Time 0 to 4294967295 --- --- F003 0
83F3 EGD Slow Producer Exchange 1 Size 0 to 65535 --- 1 F001 0
83F4 ...Repeated for EGD Slow Producer Exchange 2
EGD Fast Production (Read/Write Setting)
8400 EGD Fast Producer Exchange 1 Function 0 to 1 --- 1 F102 0 (Disabled)
8401 EGD Fast Producer Exchange 1 Destination 0 to 4294967295 --- 1 F003 0
8403 EGD Fast Producer Exchange 1 Data Rate 50 to 1000 ms 50 F001 1000
8404 EGD Fast Producer Exchange 1 Data Item 1 (20 items) 0 to 65535 --- 1 F001 0
8418 Reserved (80 items) --- --- --- F001 0
EGD Slow Production (Read/Write Setting) (2 modules)
8468 EGD Slow Producer Exchange 1 Function 0 to 1 --- 1 F102 0 (Disabled)
8469 EGD Fast Producer Exchange 1 Destination 0 to 4294967295 --- 1 F003 0
846B EGD Slow Producer Exchange 1 Data Rate 500 to 1000 ms 50 F001 1000
846C EGD Slow Producer Exchange 1 Data Item 1 (50 items) 0 to 65535 --- 1 F001 0
849E Reserved (50 items) --- --- --- F001 0
84D0 ...Repeated for EGD Exchange 2
FlexState Settings (Read/Write Setting)
8800 FlexState Parameters (256 items) 0 to 4294967295 --- 1 F300 0
Digital Elements (Read/Write Setting) (48 modules)
8A00 Digital Element 1 Function 0 to 1 --- 1 F102 0 (Disabled)
8A01 Digital Element 1 Name --- --- --- F203 “Dig Element 1“
8A09 Digital Element 1 Input 0 to 4294967295 --- 1 F300 0
8A0B Digital Element 1 Pickup Delay 0 to 999999.999 s 0.001 F003 0
8A0D Digital Element 1 Reset Delay 0 to 999999.999 s 0.001 F003 0
8A0F Digital Element 1 Block 0 to 4294967295 --- 1 F300 0
8A11 Digital Element 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
8A12 Digital Element 1 Events 0 to 1 --- 1 F102 0 (Disabled)
8A13 Digital Element 1 Pickup LED 0 to 1 --- 1 F102 1 (Enabled)
8A14 Reserved (2 items) --- --- --- F001 0
8A16 ...Repeated for Digital Element 2
8A2C ...Repeated for Digital Element 3
8A42 ...Repeated for Digital Element 4
8A58 ...Repeated for Digital Element 5
8A6E ...Repeated for Digital Element 6
8A84 ...Repeated for Digital Element 7
8A9A ...Repeated for Digital Element 8
8AB0 ...Repeated for Digital Element 9
8AC6 ...Repeated for Digital Element 10
Table B–10: MODBUS MEMORY MAP (Sheet 38 of 64)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
