GE Multilin G30 Generator Protection System B-63
APPENDIX B B.4 MEMORY MAPPING
B
C3E8 ...Repeated for Virtual Output 88
C3F0 ...Repeated for Virtual Output 89
C3F8 ...Repeated for Virtual Output 90
C400 ...Repeated for Virtual Output 91
C408 ...Repeated for Virtual Output 92
C410 ...Repeated for Virtual Output 93
C418 ...Repeated for Virtual Output 94
C420 ...Repeated for Virtual Output 95
C428 ...Repeated for Virtual Output 96
Mandatory (Read/Write Setting or Command)
C430 Test Mode Function 0 to 2 --- 1 F245 0 (Disabled)
C431 Force VFD and LED 0 to 1 --- 1 F126 0 (No)
C432 Test Mode Initiate 0 to 4294967295 --- 1 F300 1
Clear Commands (Read/Write)
C434 Clear All Relay Records Command 0 to 1 --- 1 F126 0 (No)
Mandatory (Read Only)
C435 DSP Advanced Diagnostics Active 0 to 1 -- 1 F126 0 (No)
C436 Synchrophasor Feature Active 0 to 1 -- 1 F126 0 (No)
Mandatory (Read/Write Command)
C437 Relay Reboot Command 0 to 1 --- 1 F126 0 (No)
C438 Save Volatile Data 0 to 1 --- 1 F126 0 (No)
Clear Records (Read/Write Setting)
C452 Clear User Fault Reports Operand 0 to 4294967295 --- 1 F300 0
C454 Clear Event Records Operand 0 to 4294967295 --- 1 F300 0
C456 Clear Oscillography Operand 0 to 4294967295 --- 1 F300 0
C458 Clear Data Logger Operand 0 to 4294967295 --- 1 F300 0
C468 Clear Energy Operand 0 to 4294967295 --- 1 F300 0
C46C Clear Unauthorized Access Operand 0 to 4294967295 --- 1 F300 0
C470 Clear Platform Direct Input/Output Statistics Operand 0 to 4294967295 --- 1 F300 0
C472 Reserved (13 items) --- --- --- F001 0
Platform Direct Outputs (Read/Write Setting) (32 modules)
C600 Direct Output 1 Operand 0 to 4294967295 --- 1 F300 0
C602 Direct Output 1 Events 0 to 1 --- 1 F102 0 (Disabled)
C603 ...Repeated for Direct Output 2
C606 ...Repeated for Direct Output 3
C609 ...Repeated for Direct Output 4
C60C ...Repeated for Direct Output 5
C60F ...Repeated for Direct Output 6
C612 ...Repeated for Direct Output 7
C615 ...Repeated for Direct Output 8
C618 ...Repeated for Direct Output 9
C61B ...Repeated for Direct Output 10
C61E ...Repeated for Direct Output 11
C621 ...Repeated for Direct Output 12
C624 ...Repeated for Direct Output 13
C627 ...Repeated for Direct Output 14
C62A ...Repeated for Direct Output 15
C62D ...Repeated for Direct Output 16
C630 ...Repeated for Direct Output 17
C633 ...Repeated for Direct Output 18
C636 ...Repeated for Direct Output 19
C639 ...Repeated for Direct Output 20
C63C ...Repeated for Direct Output 21
C63F ...Repeated for Direct Output 22
Table B–10: MODBUS MEMORY MAP (Sheet 55 of 64)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
