GE Multilin G30 Generator Protection System B-75
APPENDIX B B.4 MEMORY MAPPING
B
151 Phase Overvoltage 1
152 Phase Overvoltage 2
153 Phase Overvoltage 3
156 Neutral Overvoltage 1
157 Neutral Overvoltage 2
158 Neutral Overvoltage 3
209 Transformer Percent Differential
210 Volt per Hertz 1
211 Volt per Hertz 2
214 Sensitive Directional Power 1
215 Sensitive Directional Power 2
222 Split Phase Protection
224 SRC1 VT Fuse Failure
225 SRC2 VT Fuse Failure
226 SRC3 VT Fuse Failure
227 SRC4 VT Fuse Failure
232 SRC1 50DD (Disturbance Detection)
233 SRC2 50DD (Disturbance Detection)
234 SRC3 50DD (Disturbance Detection)
235 SRC4 50DD (Disturbance Detection)
246 CT Failure
272 CT Fail 1
273 CT Fail 2
274 CT Fail 3
275 CT Fail 4
296 Accidental Energization
300 Loss Of Excitation
312 Synchrocheck 1
313 Synchrocheck 2
314 Synchrocheck 3
315 Synchrocheck 4
330 Third harmonic neutral undervoltage
336 Setting Group
337 Reset
344 Overfrequency 1
345 Overfrequency 2
346 Overfrequency 3
347 Overfrequency 4
352 Underfrequency 1
353 Underfrequency 2
354 Underfrequency 3
355 Underfrequency 4
356 Underfrequency 5
357 Underfrequency 6
388 Selector switch 1
389 Selector switch 2
390 Control pushbutton 1
391 Control pushbutton 2
392 Control pushbutton 3
393 Control pushbutton 4
394 Control pushbutton 5
395 Control pushbutton 6
396 Control pushbutton 7
Bitmask Element
400 FlexElement 1
401 FlexElement 2
402 FlexElement 3
403 FlexElement 4
404 FlexElement 5
405 FlexElement 6
406 FlexElement 7
407 FlexElement 8
408 FlexElement 9
409 FlexElement 10
410 FlexElement 11
411 FlexElement 12
412 FlexElement 13
413 FlexElement 14
414 FlexElement 15
415 FlexElement 16
420 Non-volatile Latch 1
421 Non-volatile Latch 2
422 Non-volatile Latch 3
423 Non-volatile Latch 4
424 Non-volatile Latch 5
425 Non-volatile Latch 6
426 Non-volatile Latch 7
427 Non-volatile Latch 8
428 Non-volatile Latch 9
429 Non-volatile Latch 10
430 Non-volatile Latch 11
431 Non-volatile Latch 12
432 Non-volatile Latch 13
433 Non-volatile Latch 14
434 Non-volatile Latch 15
435 Non-volatile Latch 16
530 Frequency Rate of Change 1
531 Frequency Rate of Change 2
532 Frequency Rate of Change 3
533 Frequency Rate of Change 4
544 Digital Counter 1
545 Digital Counter 2
546 Digital Counter 3
547 Digital Counter 4
548 Digital Counter 5
549 Digital Counter 6
550 Digital Counter 7
551 Digital Counter 8
692 Digital Element 1
693 Digital Element 2
694 Digital Element 3
695 Digital Element 4
696 Digital Element 5
697 Digital Element 6
698 Digital Element 7
699 Digital Element 8
700 Digital Element 9
Bitmask Element
