GE Multilin G30 Generator Protection System B-77
APPENDIX B B.4 MEMORY MAPPING
B
F126
ENUMERATION: NO/YES CHOICE
0 = No, 1 = Yes
F127
ENUMERATION: LATCHED OR SELF-RESETTING
0 = Latched, 1 = Self-Reset
F128
ENUMERATION: CONTACT INPUT THRESHOLD
0 = 17 V DC, 1 = 33 V DC, 2 = 84 V DC, 3 = 166 V DC
F129
ENUMERATION: FLEXLOGIC TIMER TYPE
0 = millisecond, 1 = second, 2 = minute
F131
ENUMERATION: FORCED CONTACT OUTPUT STATE
0 = Disabled, 1 = Energized, 2 = De-energized, 3 = Freeze
F133
ENUMERATION: PROGRAM STATE
0 = Not Programmed, 1 = Programmed
F134
ENUMERATION: PASS/FAIL
0 = Fail, 1 = OK, 2 = n/a
F137
ENUMERATION: USER-PROGRAMMABLE PUSHBUTTON
FUNCTION
0 = Disabled, 1 = Self-Reset, 2 = Latched
F141
ENUMERATION: SELF TEST ERRORS
913 User-Programmable Pushbutton 14
914 User-Programmable Pushbutton 15
915 User-Programmable Pushbutton 16
916 Frequency out-of-band accumulation 1
917 Frequency out-of-band accumulation 2
920 Disconnect switch 1
921 Disconnect switch 2
922 Disconnect switch 3
923 Disconnect switch 4
924 Disconnect switch 5
925 Disconnect switch 6
926 Disconnect switch 7
927 Disconnect switch 8
928 Disconnect switch 9
929 Disconnect switch 10
930 Disconnect switch 11
931 Disconnect switch 12
932 Disconnect switch 13
933 Disconnect switch 14
934 Disconnect switch 15
935 Disconnect switch 16
968 Breaker 1
969 Breaker 2
970 Breaker 3
971 Breaker 4
1012 Thermal overload protection 1
1013 Thermal overload protection 2
Bitmask Element
Bitmask Error
0 Any Self Tests
1 IRIG-B Failure
2 Port 1 Offline
3 Port 2 Offline
4 Port 3 Offline
5 Port 4 Offline
6 Port 5 Offline
7 Port 6 Offline
8 RRTD Communications Failure
9 Voltage Monitor
10 FlexLogic Error Token
11 Equipment Mismatch
12 Process Bus Failure
13 Unit Not Programmed
14 System Exception
15 Latching Output Discrepancy
17 Maintenance Alert 01
18 SNTP Failure
19 Maintenance Alert
20 Maintenance Alert
21 Maintenance Alert
22 Temperature Monitor
23 Process Bus Trouble
24 Brick Trouble
25 Field RTD Trouble
26 Field TDR Trouble
27 Remote Device Offline
28 Direct Device Offline
29 Maintenance Alert
30 Any Minor Error
31 Any Major Error
33 Maintenance Alert
64 Maintenance Alert
65 IEC 61850 Data Set
66 Aggregator Error
