B-86 G30 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F245
ENUMERATION: TEST MODE FUNCTION
F246
ENUMERATION: BRICK TRANSDUCER RANGE
F247
ENUMERATION: BRICK AC BANK ORIGIN
F248
ENUMERATION: BRICK AUX BANK ORIGIN
F253
ENUMERATION: BRICK TRANSDUCER ORIGIN
F256
ENUMERATION: BRICK ORIGIN/DESTINATION
F259
ENUMERATION: BRICK RTD TYPE
0 = 100 Ohm Nickel, 1 = 120 Ohm Nickel, 2 = 100 Ohm Platinum
F260
ENUMERATION: DATA LOGGER MODE
0 = Continuous, 1 = Trigger
F261
ENUMERATION: BANK REDUNDANCY TYPE
0 = None, 1 = Dependability Biased, 2 = Security Biased
Value Instance
0Disabled
1 Isolated
2 Forcible
Value Description
0 -5...5V
1 -1...1mA
2 0...1mA
3 0...-1mA
4 0...5mA
5 0...10mA
6 0...20mA
7 4...20mA
8 potentiometer
9 tap position
Value Description
0None
1 U1/AC1..3
2 U1/AC5..7
3 U2/AC1..3
4 U2/AC5..7
5 U3/AC1..3
6 U3/AC5..7
7 U4/AC1..3
8 U4/AC5..7
9 U5/AC1..3
10 U5/AC5..7
11 U6/AC1..3
12 U6/AC5..7
13 U7/AC1..3
14 U7/AC5..7
15 U8/AC1..3
16 U8/AC5..7
Value Description
0None
1U1/AC4
2U1/AC8
3U2/AC4
4U2/AC8
5U3/AC4
6U3/AC8
7U4/AC4
8U4/AC8
9U5/AC4
10 U5/AC8
11 U6/AC4
12 U6/AC8
13 U7/AC5
14 U7/AC8
15 U8/AC5
16 U8/AC8
Value Description
0None
1 U1/DC1
2 U1/DC2
3 U1/DC3
4 U2/DC1
... ...
24 U8/DC3
Value Description
0None
1U1
2U2
3U3
4U4
5U5
6U6
7U7
8U8
Value Description
