User manual
HOUR METER MENU
The hour meter function indicates the total time in which the output
remained in the on status.
The hour meter range is between 0 and 99999 hours, when the
maximum limit is reached, it is automatically reset.
To display the hour meter value:
➢ from the main page, press “
”
➢ select HOUR CNT with “C1” and “C2”
➢ press “Ok” to confirm
➢ choose with “C1” and “C2”, in the
case of GLX+Q 1 2COM 16A 2M AST
IR, sets program 1 on relay 1.
➢ press “Ok”. The total use is displayed
➢ press “Ok” again to access the hour
meter reset option. Press “Ok” again
to confirm or “
” to exit without
resetting.
➢ The message
appears on
the display to indicate the change that
was made.
RESET MENU
The instrument’s default status can be reset with the reset function.
There are 4 different resets available:
- reset settings: deletes all settings that were made
- reset programmes: deletes all saved programs
- reset hour meter: resets the operating time hour meter
- reset all: reset settings + reset programs + reset hour meter
To perform the reset:
➢ press “
” to access the menu
➢ select RESET with the keys “C1” and “C2” and press “Ok”
➢ use the keys “C1” and “C2” to select one of the above listed resets
and press “Ok”
➢ press “Ok” to confirm.
To perform a complete instrument reset, restoring the factory settings,
use a sharp instrument to press the “R” key. This deletes all the
settings that were made and restores the default conditions.
