User manual
IR INTERFACE
The switches (GLX+Q 1 1COM 16A 2M AST IR and GLX+Q 1 2COM
16A 2M AST IR) have an IR interface that makes it easy to exchange
programs between the instrument and its remote control.
Attention: the IR interface can only be activated if GLX+Q AST is
powered by the mains network.
In this way, an instrument can be programmed, then the program can
be copied to a remote control and then duplicated in other instruments,
without having to repeat the programming step by step.
The program exchange remote control is not provided with the
instrument but can be purchased separately as an accessory:
Code Model Description
687456 GLX+IR IR remote control Ita/Eng/Fra/Deu/Esp
There are two basic functions in this operating mode:
- COPY: consists in transferring the programs from a GLX+Q AST to
the remote control
- PASTE: consists in transferring the programs from a remote control
to one or more than one GLX+Q AST instruments at the same time.
Copy function
To transfer a program from GLX+Q AST to the remote control, first:
➢ generate a program with the traditional method onl GLX+Q AST
(see “Automatic programming”)
➢ activate the reception mode on the remote control (see the relative
instruction sheet)
➢ activate the transmission on
GLX+Q AST, holding down the “Ok”
key for 3 seconds
The following message will appear
on the display
➢ press the “Ok” key again to confirm
the start of transmission or “
”
to cancel the transmission
➢ during the transmission, the following
message will appear on the display
( on the remote
control display) and the remote control will emit “bips”.
When completed, the following message is displayed
.
C1 C2
R
Ok
3 seconds
