To remove the Backsplash bottom,

remove the 2- ¼ inch Hex screws, 1 on

each side under the trim cap.

BACKSPLASH BOTTOM

Then slide the Backsplash Bottom toward

the rear of the washer and out .

Lid Assembly

Removal

Trim

Cap
