Disconnect power to the washer. Access
the control.
Disconnect the J701 connecter.
Check the resistance from the
YELLOW WIRE to the WHITE WIRE
at the J101 connecter. Should read
approximately 16.5 OHM.
If Resistance is good, check for 120vac
at the same locations.
Diagnostics From The Board
Drain Pump
N
E
U
T
88
