Bottom of Subwasher
Mode Shifter
Mode Shifter cannot be Removed Without removing the Stator. (See
Stator Removal )
Disconnect the Harness to the Mode Shifter and Disengage the
wire hold down, aka-Christmas tree, from the Platform. ( See Side
Photos)
Then Remove the 3- T20 Torques Screws
Pull Mode Shifter up and off the Platform
Mode
Shifter
Torque
Screws
