Diagnostics From The Board
Mode Shifter Motor Resistance
Check the Mode
Shifter Motor
Resistance from
J701 connecter
ORANGE WIRE to
the WHITE
Neutral wire on
the J101
connecter. Should
read approximately
4K Ohm. If
Resistance is good,
check for 120vac at
the same locations.
89
