GE GTWN7450DWW

Bottom of Subwasher
Mode Shifter Assembly
Mode Shifter will come
as a Complete Assembly
When Replacing the
Mode Shifter
Assembly be sure to
insert the spring
properly. It needs to
fit Into the groove.
Torque for the Mode Shifter Screws is 17in lbs.
When installing the
clutch, make sure if
moves freely up and
down while lining up
the teeth.
Make sure also to Install flat washer for
the spring to be supported on platform.
