HOT LIPS TUBE SEALER Operator Manual 87-4500-07 AI 19
Operation 3
Setting the tubing type and size 3.3
3.3 Setting the tubing type and size
Step User action Response LCD display
2A
Press the MENU button. The LCD will show “SELECT TUBING” with
the current setting displayed.
2B
Press the cursor up button
or cursor down button
cursor keys until the
desired tubing type and
diameter are displayed.
The LCD will scroll through all the
available tubing combinations.
2C
Press the Enter ( ) button
to select this tubing.
Press the MENU button to
abort the selection and
retain the original setting.
The parameters for the selected tubing
are loaded. A beep will confirm load
complete.
This setting will be retained even when
power is turned off.
SELECT TUBING
CFLEX 3/8 × 5/8
SELECT TUBING
PVC 1/2 × 3/4
Press to
select
INSERT TUBING
PVC 1/2 × 3/4
