HOT LIPS TUBE SEALER Operator Manual 87-4500-07 AI 11
Introduction 1
HOT LIPS TUBE SEALER 1.4
1.4 HOT LIPS TUBE SEALER
Introduction
The HOT LIPS TUBE SEALER is a fully automated unit designed to seal thermoplastic
tubing. The machine is useful for sealing feed, harvest and sample tubing
connected to bags or other containers, for storage and transportation. The unit is
designed to seal a wide range of tubing diameters. See Appendix A for all approved
tubing. Major uses are in bioprocessing and in aseptic applications.
Main parts
The illustration below shows the main parts of HOT LIPS TUBE SEALER.
.
NOTICE
High pressures can be generated if the liquid in the seal area has no
place to go when it is clamped down by the sealing jaws. Make sure that
the liquid can be displaced up or downstream of the seal and ensure that
the temporary clamps or plugs are secure.
Part Description
1Moving jaw
2 LCD display
3 GO button
4 LIFT UP TO LOAD TUBE handle (tube loading handle)
