Downloading your iBox Configuration over the LAN, continued
Procedure:
Downloading
your iBox
Configuration
over the LAN
To download an iBox configuration file over the LAN:
Step Action
1 In the Project window, click the iBox device icon.
2 Open the Terminal Emulator; see the SGConfig online help topic: Open
Terminal Emulator.
Result: SGConfig opens a Terminal Emulator tab.
3 Log into WESMAINT.
Result: The WESMAINT main menu appears.
4 Select option 2, System Functions.
Result: The System Functions menu appears.
5 Select option 3, 68K Monitor.
Result: The system prompt appears, indicating that the Applications
Monitor is running.
6 At the system prompt, type rtb and press ENTER.
For other available commands, type help and press ENTER.
7 At the Return to the BootROM Operating System? (yes/no) prompt,
type yes and press ENTER.
Note: The monitor is not case sensitive, but Y is not acceptable.
Result: The iBox restarts.
8 In SGConfig, open the project containing the iBox device.
9 In the project window, right-click the iBox device icon, click
Communications, and then click Configuration Download.
Result: SGConfig downloads the new configuration to the iBox.
SGConfig displays progress messages until the new
configuration has been successfully downloaded.
Note: The iBox does not need to be rebooted for the new configuration
to be effective.
10 Exit SGConfig.
