GE iBox User Manual

GE Grid Solutions
iBox/iBox Kit
Installation and Maintenance Guide
GE Information
994-0047-5.10-4
147
Technical Specifications – iBox Kit, continued
Digital Inputs
General
Up to eight bipolar optically isolated (2000 V
rms
)
Physical
250 V rated compression termination consisting of a
header and removable plugs suitable for 12 – 24 AWG
wire 0.01A/150V
Burden
• From 1.9 mA to 5.5 mA
• Max. power dissipation is 0.5 W per input
Wetting Options
• External wetting - for all input options
• Modes of operation:
− Dry contact and voltage sense
− 24 VDC, 48 VDC, and 110/125 VDC
Digital
Outputs
General
Up to four relay outputs, configured as either:
• 4 trip/close pairs or
• 2 trip/close pairs and 2 Form A contacts
Physical Connection
250 V rated compression termination consisting of a
header and removable plugs suitable for 12 – 24 AWG
wire rated for 6A/150V
Security features
• Separate Master Trip and Master Close relays
• Single point of failure integrity, select-before-operate
(SBO) functionality.
• Remote/Local jumper JP2
Control Voltage
External
Switching Characteristics
• 35 W breaking @ 150 VDC
• 180 W breaking @ 30 VDC
Maximum Carrying
Current
6 A
Continued on next page
