GE iBox User Manual

iBox/iBox Kit
Installation and Maintenance Guide
GE Grid Solutions
152
994-0047-5.10-4 GE Information
IBOX Kit with DC Analogs and Ethernet (IBOX-DCL)
Configuration Details Comments
DNP DPA
iBox DNP 3.0 Master Address: 10
iBox DNP 3.0 Slave Address: 1
Communication Port: COM1
Baud Rate: 9600
Communication Type: RS-232
Refer to point map tables for more detail.
DNP DPA
iBox DNP 3.0 Master Address: 10
iBox DNP 3.0 Slave Address: 1
Communication Port: Ethernet
Master IP Address: 192.168.1.200
Slave IP Address: 192.168.1.20
Subnet Mask: 255.255.255.0
Refer to point map tables for more detail.
WESMAINT
User Name: westronic
Password: rd
Control Password: control
Note: COM2 is used to connect to the Ethernet Module via PPP/TCP/IP.
Note: COM3 is used to connect the DC analog input module to the iBox.
DC Analog Input Ranges
For all bipolar inputs, regardless of whether the input is bipolar current or voltage,
the following is always true:
Input Value Value Returned to Master
Maximum negative input
-32768
Zero input
0
Maximum positive input
32767
However, for the 4-20 mA input, the following values are returned by the iBox to the
master:
Input Value Value Returned to Master
Any input in the range of 0 to 4 mA
-32768
Half of Full Scale (12 mA)
0
Maximum input (20 mA)
32767
